Stainless Steel 304/304l/304h Sheets Manufacturer | Stainless Steel 304/304L/304H Sheets Suppliers | Authorised Distributor & Stockist of Jindal Sheets
ASTM A240 Stainless Steel 304/304L/304H Sheets ASTM A240 | Werkstoff 1.4301/ 1.4307/ 1.4948 Of Stainless Steel 304/304L/304H Sheets
DM Metalloys Pvt. Ltd. is a foremost manufacturer, exporter and supplier of stainless steel 304/304L/304H stainless sheets in India. We supply all of the stainless steel 304/304L/304h sheets for use in the oil or natural gas industries. At our reputed organization, we want to defense that you're receiving the right kind and quality of Stainless Steel 304/304L/304H sheets, ASTM A312, ASTM A213, ASTM A249, and ASTM A554. With our extensive information, we can support your company from preservation to construction of new projects. Various sizes and stipulations are provided by us to our customers as per their requirements.
Applications of Stainless Steel 304/304L/304H Sheets
- Manufacturing Boilers
- Pressure Vessels
- Heat Exchangers for Fertilizer Plants
- Chemical Plants
- Petroleum Refineries
- Power Generation Plants
Chemical Composition of Stainless Steel 304/304L/304H Sheets
| Specification | Chemical Composition | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| JIS | AISI | C | Si | Mn | P | S | Ni | Cr | N |
| SUS304 | 304 | Max.0.08 | Max.1.00 | Max.2.00 | Max.0.045 | Max.0.030 | 8.00~10.50 | 18.00~20.00 | - |
| SUS304L | 304L | Max.0.03 | Max.1.00 | Max.2.00 | Max.0.045 | Max.0.030 | 9.00~13.00 | 18.00~20.00 | - |
| SUS304H | 304H | 0.04-0.10 | 0.75 | Max.2.00 | Max.0.045 | Max.0.030 | - | 8.00-10.50 | 0.10 |
Mechanical Property of Stainless Steel 304/304L/304H Sheets
| Grade | Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max |
Brinell (HB) max |
||||
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304L | 485 | 170 | 40 | 92 | 201 |
| 304H | 515 | 205 | 40 | 92 | 201 |
Physical Properties of Stainless Steel 304/304L/304H Sheets
| Grade | Density (kg/m3) | Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion | Thermal Conductivity | Specific Heat 0-100°C ( J/kg.K) |
Electrical Resistivity (n·.m) |
|||
|---|---|---|---|---|---|---|---|---|---|
| 0-100°C (·m/m/°C) |
0-315°C (·m/m/°C) |
0-543°C (·m/m/°C) |
at 100°C (W/m.K) | at 500°C (W/m.K) | |||||
| 304/L/H | 7900 | 193 | 17.2 | 17.8 | 18.4 | 16.3 | 21.5 | 500 | 720 |
Specification of Stainless Steel 304/304L/304H Sheets
| Standard | As per EN , DIN , JIS , ASTM , BS , ASME , AISI , etc. |
|---|---|
| Specification | ASTM A240 / ASME SA240 |
| Range | 5 mm to 100 mm thick in, 1000 mm to 2500 mm width & 2500 mm to 12500 mm length available with NACE MR 01-75s |
| Sizes Available | 0.1 mm thickness to 150 mm thickness 1000 mm x 2000 mm 1220 mm x 2440 mm (4' x 8') 1220 mm x 4880 mm 1250 mm x 2500 mm 1500 mm x 3000 To 6300 mm 2000 mm x 2000 To 10000 mm and As per requirement |
| SS Coils Thickness | 0.2 mm to 20mm |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, N0.3, Mirror, Bead Blast Finish, Satin Finish, Matte Finish, Brushed Finish, Heat Colored finish wide range of electro polished sheets colored surface, Reflective Finish , etc |
DM Metalloys Pvt. Ltd. Supplies Stainless Steel 304, 304L, 316, 316L Sheets in Faridabad, Gurgaon, Gurugram, Gaziabad, Noida, Lukhnow, Delhi, Delhi NCR, Ludhiana, Amritsar, Chandigarh, Jalandhar, Baddi, Punjab, Uttar Pradesh, Haryana, Mumbai, Pune, Sahibabad, Meerut, Manesar, Bhiwadi, Bawal, Neemrana, SIDCUL, Sonepat, Ambala, Mohali, Panchkula, Kapurthala, Bareli, Kanpur.
