Stainless Steel 304/304L/304H Strips ASTM A240 | Werkstoff 1.4301/ 1.4307/ 1.4948 of Stainless Steel 304/304L/304H Strips
DM Metalloys Pvt. Ltd. leading manufacturer of stainless steel 304/304L/304H strips. 304/304L/304H Stainless Steel Strips, are a piece of the austenitic group of stainless steel and they are a standout between the most flexible and generally exploited assortments of stainless plate. They are a moderately minimal effort stainless item and utilized as a share of an assortment of utilizations. 304 evaluations have astonishing low temperature properties and react well to solidifying by chilly working. 304 evaluations have great welding characteristics and post weld tempering is not typically required to regenerate execution. 304 SS has amazing erosion resistance in an assortment of various media.
Applications of Stainless Steel 304/304L/304H Strips
- Manufacturing Boilers
- Pressure Vessels
- Heat Exchangers for Fertilizer Plants
- Chemical Plants
- Petroleum Refineries
- Power Generation Plants
Chemical Composition of Stainless Steel 304/304L/304H Strips
| Specification | Chemical Composition | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| JIS | AISI | C | Si | Mn | P | S | Ni | Cr | N |
| SUS304 | 304 | Max.0.08 | Max.1.00 | Max.2.00 | Max.0.045 | Max.0.030 | 8.00~10.50 | 18.00~20.00 | - |
| SUS304L | 304L | Max.0.03 | Max.1.00 | Max.2.00 | Max.0.045 | Max.0.030 | 9.00~13.00 | 18.00~20.00 | - |
| SUS304H | 304H | 0.04-0.10 | 0.75 | Max.2.00 | Max.0.045 | Max.0.030 | - | 8.00-10.50 | 0.10 |
Mechanical Property of Stainless Steel 304/304L/304H Strips
| Grade | Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max |
Brinell (HB) max |
||||
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304L | 485 | 170 | 40 | 92 | 201 |
| 304H | 515 | 205 | 40 | 92 | 201 |
Physical Properties of Stainless Steel 304/304L/304H Strips
| Grade | Density (kg/m3) | Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion | Thermal Conductivity | Specific Heat 0-100°C ( J/kg.K) |
Electrical Resistivity (n·.m) |
|||
|---|---|---|---|---|---|---|---|---|---|
| 0-100°C (·m/m/°C) |
0-315°C (·m/m/°C) |
0-543°C (·m/m/°C) |
at 100°C (W/m.K) | at 500°C (W/m.K) | |||||
| 304/L/H | 7900 | 193 | 17.2 | 17.8 | 18.4 | 16.3 | 21.5 | 500 | 720 |
Specification of Stainless Steel 304/304L/304H Strips
| Standard | As per EN , DIN , JIS , ASTM , BS , ASME , AISI , etc. |
|---|---|
| Specification | ASTM A240 / ASME SA240 |
| Range | 5 mm to 100 mm thick in, 1000 mm to 2500 mm width & 2500 mm to 12500 mm length available with NACE MR 01-75s |
| Sizes Available | 0.1 mm thickness to 150 mm thickness 1000 mm x 2000 mm 1220 mm x 2440 mm (4' x 8') 1220 mm x 4880 mm 1250 mm x 2500 mm 1500 mm x 3000 To 6300 mm 2000 mm x 2000 To 10000 mm and As per requirement |
| SS Coils Thickness | 0.2 mm to 20mm |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, N0.3, Mirror, Bead Blast Finish, Satin Finish, Matte Finish, Brushed Finish, Heat Colored finish wide range of electro polished sheets colored surface, Reflective Finish , etc |
DM Metalloys Pvt. Ltd. Supplies Stainless Steel 304/304L/304H Strips in Faridabad, Gurgaon, Gurugram, Gaziabad, Noida, Lukhnow, Delhi, Delhi NCR, Ludhiana, Amritsar, Chandigarh, Jalandhar, Baddi, Punjab, Uttar Pradesh, Haryana, Mumbai, Pune, Sahibabad, Meerut, Manesar, Bhiwadi, Bawal, Neemrana, SIDCUL, Sonepat, Ambala, Mohali, Panchkula, Kapurthala, Bareli, Kanpur.
